Allen-Bradley 1756-IF6I 6-channel modules analog input module
allen bradley controllogix
,rockwell parts
Product:Allen-Bradley 1756-IF6I
6-channel modules analog input module
The 6-channel modules can refer to the following:
• 1756-IF6CIS • 1756-IF6I • 1756-IR6I • 1756-IT6I • 1756-IT6I2 • 1756-OF6CI • 1756-OF6VI
The 8-channel modules can refer to the following: • 1756-IF8I • 1756-IRT8I • 1756-OF8I
The 8-channel modules use different RTBs than their predecessors. This means that the wiring and terminals used are different across the various modules. There are various 1492 wiring solutions available for the 8-channel modules.
If your existing 6-channel application is already wired using a 1492-AIFMxxx interface module, then you may be able to convert to a new analog module by replacing the 1492 cable.
For example, if you have an existing application with a 1756-IF6I module used in Voltage mode that is wired with 1492 products, you would be using a 1492-AIFM6S-3 terminal block. Attached to the terminal block, you would have a 1492-ACABLExxxY cable. You could replace the 1756-IF6I module with a 1756-IF8I module, keep all wires intact to the 1492-AIFM6S-3 terminal block, remove the 1492-ACABLExxxY cable, and replace it with a 1492-ACABLExxxYB cable. The new cable is configured to adjust the current 6-channel field wiring into the appropriate terminals on the new 8-channel module. Then you would be finished with minimal cost and effort.
