IC693CHS392 GE Expansion Baseplates Figures 3-6 And 3-7
Category:
General Electric PLC
Payment Method:
T/T, Western Union
Specifications
Price:
Enquiry
Warranty:
One Year
Payment Item:
T/T,Western Union
Delivery Time:
3-5 Days
Delivery Way:
Air Freight
Return:
Within 15 Days
Brand:
General Electric
Model:
IC693CHS392
High Light:
GE Expansion Baseplates
,GE IC693CHS392
,Expansion Baseplates IC693CHS392
Introduction
IC693CHS392 GE Expansion Baseplates (Figures 3-6 and 3-7) IN STOCK
Product Description:
- There can be no more than a total of 50 feet (15 meters) of cable interconnecting Expansion baseplates and the CPU baseplate.
- An Expansion baseplate cannot stand alone. It must be connected to a system that has a CPU. The CPU can be in a PLC or in a Personal Computer that is equipped with a Personal Computer Interface Card (see Chapter 11).
- Maximum number of Expansion baseplates allowed per system depends on the type of CPU they are used with. For CPUs 331, 340, and 341, the maximum is 4. For CPUs numbered 350 and higher, the maximum is 7.
- Each Expansion baseplate has a 25-pin female D-type I/O Bus Expansion connector mounted at its right end for connection to other baseplates. Available in two versions; 5-slot (IC693CHS398) and 10-slot (IC693CHS392)
- An Expansion backplane does not support the following intelligent option modules: PCM, ADC, BEM330, and CMM. These modules must be mounted in a CPU baseplate. All other I/O and option modules can be mounted in any type of rack.
- All Expansion baseplates must be connected to a common ground (see the “Installation” chapter for details).
- Expansion baseplates are the same physical size, use the same type power supplies, and support the same I/O and option modules as the Remote baseplates.
- Each Expansion baseplate has a Rack Number Selection DIP switch
