A6824 Emerson ModBus and Rack Interface Specifications

• 3U size, 1-slot plug-in module decreases cabinet space requirements in half from traditional 6U size cards

• API 670 compliant, hot swappable module

• Password protected user configuration

• Self-checking facilities include monitoring hardware, power input, and hardware temperature

• A6824 module can serve multiple 19” racks

• A6824 is a 6TE wide module, no redundant option, for use in the IMR6000 series, 19” rack

• A6824R is a 4TE wide module, redundancy optional, for use in the IMR6500 se

The ModBus and Rack Interface Module is designed for high reliability for the plant’s most critical rotating machinery. It reads parameters from all AMS 6500 modules and outputs these parameters via ModBus TCP/IP and/or ModBus RTU (serial). This 1-slot monitor is used together with other AMS 6500 monitors to build a complete API 670 machinery protection monitor. Applications include steam, gas, compressors and hydro turbo machinery.

The AMS 6500 is an integral part of PlantWeb® and AMS software. PlantWeb provides operations integrated machinery health combined with the Ovation® and DeltaV™ process control system. AMS software provides maintenance personnel advanced predictive and performance diagnostic tools to confidently and accurately determine machine malfunctions early.

We are the supplier for industrial automation spare parts. We specialize in PLC module, DCS card pieces, ESD system card pieces, vibration monitoring system card pieces, steam turbine control system module, gas generator spare parts. We have established the relationship with famous PLC DCS product maintenance service providers in the world.

Our products are widely used in CNC machinery and metallurgy, oil and gas, petrochemical, chemical, paper printing, textile printing and dyeing, machinery, electronics manufacturing, automobile manufacturing, tobacco, plastic machinery, electricity, water conservancy, water treatment / environmental protection, municipal engineering, heating, energy, transmission and distribution industries.
