Features:
- Supplies Operating Voltages to Both Harmony Block and Rack Equipment
- Selectable N, N+1, N+x, and 2N Power Supply Redundancy
- 260 Watts Output Per Module
When two power sources are utilized the Modular Power System II can be split into two sections with four power module slots per section. This 2N split architecture offers the highest level of power availability. Each section supplies only 50 percent of the load under normal conditions but is capable of supplying 100 percent of the load under a failure condition. The low stress at 50 percent of capacity assures a long lifetime.
When only one power source is used to supply secure power to the Modular Power System II, the two sections of the split architecture are strapped together providing N+x power architecture. Each power module is supplied from one source and shares the load equally.
