UPC090AE01 HIEE300661R0001 ABB
Product Details
| Brand | ABB | Module Numeber | UPC090AE01 HIEE300661R0001 |
|---|---|---|---|
| Catalog | VFD Spares | HS Code | 8537101190 |
| Sales Price | $1700 | Condition | In Stock |
| Origin | Sweden | Lead Time | 3-5 Working Days |
| Warrenty | 1 Year | Gross Weight/Shipping Weight | 2.2 Lbs / 35.2 Oz / 1kg |
| Packing Size | 16cm X 16 Cm X 12 Cm | Courier Partners | DHL, UPS, TNT, FedEx And EMS |
| Highlight | 16-channel digital inputs ABB Module,24 V DC input voltage Input/Output Module,500 V AC isolation voltage Profibus-DP Coupler |
||
Product Description
UPC090AE01 HIEE300661R0001 ABB
| Brand Name | ABB |
| Model | UPC090AE01 |
| Ordering Information | HIEE300661R0001 |
| Catalog Description | VFD Spares |
| Gross Weight | 2.2 lbs / 35.2 oz / 1kg |
| Packing Size | 16cm x 16cm x 12cm |
| Country of Origin | Sweden |
| HS Code | 8537101190 |
| Lead Time | In Stock |
| Shipping Port | Xiamen |
| Payment | T/T |
| Sales Price | $1700 |
| Warranty | 12 months |
| Lead Time | 3-5 work days |
| Courier Partners | DHL, UPS, TNT, FedEx and EMS |
Product Description
The UPC090AE01 HIEE300661R0001 is a multi-channel input/output module. This module is part of ABB's classic Freelance AC 700F controller series and is designed for industrial control systems, particularly distributed control systems (DCS) and programmable logic controllers (PLC).
This module can function as a fieldbus coupler (Profibus-DP coupler). One end is tightly connected to an AC 700F or compatible controller rack via a high-speed parallel bus, enabling direct communication with the CPU; the other end features a standard 9-pin D-SUB connector for connecting to a Profibus-DP fieldbus network.
It can also function as a process controller module or multifunction processor, handling core computational and control tasks; versions with AC/DC power supply modules are also available to provide a stable power supply for DCS systems. This multifunctional design makes it one of the core components in the ABB DCS/PLC system.
Key Features
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -40°C to +85°C
- IP20 protection rating, suitable for installation inside control cabinets
- 16-channel digital inputs (digital input version), active-high, electrically isolated
- Input voltage: 24 V DC (±10%), input current 7 mA per channel, input impedance approximately 3.5 kΩ
- Response time less than 10 ms, fast and stable signal acquisition
- 500 V AC isolation voltage (between channels and between channels and ground)
- Complies with global safety standards such as CE, UL, and IEC 61131-2
Installation Precautions
- Verify that the system backup is complete, and use Composer or WinGP software to back up the current controller configuration
- Verify that the firmware version of the new module is compatible with the original system
- Verify that the backup battery is installed correctly (the battery protects the configuration data in RAM; if the battery fails, the program will be lost after a power outage)
- Ensure the controller is in standby mode (for redundant systems) or switch the relevant control loops to manual mode before turning off the power
- Remove the old module and check that the pins on the backplane are free of corrosion and not bent
- Slide the new UPC090AE01 module along the rail, press it down evenly until it is fully seated, and tighten the mounting screws
- The installation method is standard DIN rail mounting, compatible with industrial cabinets
Case Study
After confirming that the original controller hardware had aged, a large thermal power plant decided to replace it with the UPC090AE01 as the core processing unit in the control network, responsible for complex logical operations and closed-loop control.
After a period of operation, the controller's load factor dropped from 85% to 45%, and the redundancy switchover test time was zero delay. The boiler combustion control loop returned to stable operation, the quality of AGC control improved significantly, and the unit's stable operation during peak-shaving conditions was successfully ensured.
Frequently Asked Questions
What wiring methods does the UPC090AE01 support?
It supports both screw and spring wiring methods. Users can choose the most suitable wiring method based on their specific application.
It supports both screw and spring wiring methods. Users can choose the most suitable wiring method based on their specific application.
How is the UPC090AE01 installed?
The UPC090AE01 uses a standard DIN rail mounting method, is compatible with industrial cabinets, and is easy to deploy quickly.
The UPC090AE01 uses a standard DIN rail mounting method, is compatible with industrial cabinets, and is easy to deploy quickly.
Can the UPC090AE01 be replaced on-site?
Yes, the UPC090AE01 is designed as a plug-in unit that can be quickly replaced during maintenance. When replacing it, be sure to take precautions against static electricity and follow the correct operating procedures.
Yes, the UPC090AE01 is designed as a plug-in unit that can be quickly replaced during maintenance. When replacing it, be sure to take precautions against static electricity and follow the correct operating procedures.
Recommended Products
| Product Code | Model |
|---|---|
| CI840A 3BSE041882R1 | SPDSO14 |
| CI840 3BSE022457R1 | SPFCS01 |
| CI853K01 3BSE018103R1 | SPFEC12 |
| DI814 3BUR001454R1 | SPHSS13 |
| CI851K01 3BSE018101R1 | SPNPM22 |
| AI830 3BSE008518R1 | SPSED01(SED01) |
| AI830A 3BSE040662R1 | CP800 |
| AI845 3BSE023675R1 | IMASI13 |
| AI895 3BSC690086R1 | HC800 |
| AO810V2 3BSE038415R1 | BRC400 |
Contact Information
Contact Person: Nelly Yang
Email: sales12@htechplc.com
Phone/Skype/Whatsapp: +86 18060985064
Email us now for competitive pricing and professional service!
